| Interior Height: |
6'6” |
| Interior Width: |
96” |
| Exterior Aluminum: |
.030” |
| Wheels: |
15” maxis Radials on Silver Mod Rims
w/Chrome Caps |
Frame:
aaaTags
aaaGooseneck |
Z Tech Protective Coating
6” I Beam – 4 Foot Beavertail
8” Tube – 4 Foot Beavertail |
| Torsion Axles: |
Dexter E-Z Lube – All Wheel Electric Brakes
82” between Wheel Bells. |
| Wall Construction: |
1” x 1 ½” Steel Tube |
| 16” Centers |
Walls, Ceiling & Floors |
| Flooring |
¾” Plywood with Darco Moisture Barrier |
| Walls |
White Vinyl |
| Ceiling |
White Vinyl |
| Insulation |
Ceiling |
| Side Door |
48” with Flush Lock and Deadbolt – Piano Hinge |
| Ramp Door |
Spring Assisted with Cambars and 16” Flap |
| Roof |
1 Pc. Aluminum |
| Radius Corner |
Brite Anodize |
| Bull-Nose |
Front Cast Corners with Brite Anodized Top Wrap |
| Electric |
2 – 12V Lights with Switch |
| Breakway Kit |
Standard |
| Fenders |
Aluminum Teardrop |
| Stoneguard |
Standard on Gooseneck Only |
| 3rd Member |
48” Triple Tube Tongue |
| Grab Handles |
(2) Standard on Ramp Door |
| Back End |
Wrapped with Mill Finish Aluminum |
| Tail Lights |
L.E.D. in Uprights |
| Warranty |
3 Year Factory Warranty |
|
OPTIONS: |
• ATP Stoneguard
• Spring Cover
• Roof Vent
• Electrical Packages
• Cabinet Packages
• Hydraulic Jack (Gooseneck)
• Air Conditioning
• Vinyl Flooring
• Electric Tongue Jack (Tag) |
